Redispersible Polymer Powder (RDP) in Tile Adhesive Formulation

The described redispersible polymer powder (RDP), based on a vinyl acetate/ethylene (VAE) copolymer with polyvinyl alcohol (PVOH) as a protective colloid, is an excellent additive for optimizing C1 & C2 tile adhesives.



The described redispersible polymer powder (RDP), based on a vinyl acetate/ethylene (VAE) copolymer with polyvinyl alcohol (PVOH) as a protective colloid, is an excellent additive for optimizing C1 & C2 tile adhesives. Below is a breakdown of its role, benefits, and application considerations:

Core Components & Mechanism

VAE Copolymer: Combines the adhesion of vinyl acetate with the flexibility of ethylene.

PVOH Protective Colloid: Ensures stability during spray-drying and redisperses in water during mixing, forming a polymer film that enhances cohesion and adhesion.

Spray-Dried Form: Enables easy handling, storage, and compatibility with dry-mix formulations.

Performance Benefits in Tile Adhesives

Adhesion Strength

Tensile Bonding: PVOH enhances substrate wetting, while VAE forms a flexible film, ensuring strong adhesion to ceramics, concrete, and other substrates.

C1/C2 Compliance: Meets EN 12004 standards for adhesion strength (≥0.5 MPa for C1, ≥1.0 MPa for C2 after water immersion).

Flexibility & Crack Bridging

Ethylene content improves elongation, allowing the adhesive to accommodate substrate movement and thermal stresses without cracking.

Workability

Enhances open time (adjustability) and smooth application due to improved water retention from PVOH. Reduces sagging on vertical surfaces.

Durability

Water Resistance: Hydrophobic ethylene units reduce water uptake, critical for wet areas (e.g., bathrooms).

Abrasion Resistance: Polymer film reinforces the cement matrix, improving wear resistance and color stability.

Cost Efficiency

Lower dosage required compared to rigid polymers (e.g., pure vinyl acetate), balancing performance and cost.

Formulation Tips

C1 vs. C2: For C2, increase RDP dosage (typically 1.5–3% by weight) and ensure proper cement (e.g., CEM I 52.5R) and filler ratios.

Synergy with Additives:

Combine with cellulose ethers (e.g., HPMC) for water retention and workability.

Use silica sand for mechanical strength and anti-slip agents (e.g., fumed silica) for vertical application.

Mixing: Ensure thorough dispersion in dry mix before water addition to avoid clumping.

Why VAE Over Alternatives?

Compared to acrylics: Lower cost, adequate flexibility for most tile applications.

Compared to pure vinyl acetate: Better crack resistance and lower brittleness due to ethylene.

Potential Limitations

Temperature Sensitivity: Avoid use in extreme heat (>35°C) during application, as PVOH may dissolve prematurely.

Alkali Stability: Ensure compatibility with high-pH cement systems (VAE is generally stable, but verify with supplier).

Standards & Compliance

EN 12004: Certifies suitability for C1 (standard adhesives) and C2 (improved adhesives with enhanced water resistance and adhesion).

EN 1348: Validates tensile adhesion strength after water immersion and heat aging.

By leveraging our RDP, customers can achieve a balance of cost, performance, and durability, making it ideal for both residential and commercial tile installations.
